E-Space EVO

Marchio: Atala
Kit Elettrico: EcoLogic 45Nm/Speed Smart
Colori: Antracite/Light Blue Matt
Taglie: 45 cm

SPECIFICHE MECCANICHE:

Telaio: Alu. 26", easy access, integrated batery, integrated HT, disc brake
Forcella: HL CH-187 26", alu with alu crown, 40mm
Serie sterzo: Integrated 1"1/8, threaded, with cap
Guarnitura: Byte steel 42T cartridge, with cap
Cambio: Shimano Tourney RD-TY500
Comandi: Shimano Tourney SL-RS35 RevoShift, 7s
Freni: Tektro Aries MD-M300, Mechanic disk, Rotor 160 mm, with brake lever switch
Ruota Libera: Shimano Tourney 7s 14-28
Pedali: Resin antislip
Mozzi: Alu 36h, quick release front, motor on rear, INT
Cerchi: Beretta 26" alu, double wall w/eylets, 36h, disc
Attacco manubrio: Byte alu, adjustable
Piega manubrio: Byte steel City
Reggisella: Byte alu with clamp, 27,2mm
Sella: Selle Royal Wave
Coperture: Byte Garda 26"x1,75"
Parafanghi: Single stay safety-clip
Copricatena: Steel painted, L type
Portapacchi: Rear carrier with spring, 25kg / front carrier
Luci esterne: Front and rear LED, controlled by display and twilight sensor
Taglia: 45 cm
Colore: Black/Light Blue Matt

SPECIFICHE ELETTRICHE:

Coppia massima: 45Nm
Tipo sensore: Speed sensor w/12 pulses
Batteria: 418 Wh

Autonomia:
level1: up to 100 km
level2: up to 72 km
level3: up to 58 km
level4: up to 45 km
level5: up to 37km

Tipo caricabatteria: 2 A
Tempo di ricarica: 100%: 6h10m / 80%: 4h40m
Velocità max assistita: 25km/h
Display: Atala A10 LCD Smart CAN, with remote control

Potenza: 5 levels, Speed/Torque adjust
level1: 11km, 27Nm
level2: 14km, 30Nm
level3: 17km, 33Nm
level4: 21km, 39Nm
level5: 25km, 45Nm
